Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour

  • Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour
  • Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour
  • Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour
  • Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour
  • Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour
  • Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour
Place of Origin China
Brand Name Ascend
Certification ISO9001
Model Number PF-1008 PF-1010 PF-1210 PF-1212 PF-1214 PF-1315
Document Product Brochure PDF
Minimum Order Quantity 1 set
Price USD 5999-6999
Packaging Details Wooden box or put in container
Delivery Time 7-15 working days
Payment Terms T/T, L/C, , D/A
Supply Ability 50 Sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Impact Crusher Discharge Size 0-40mm
Color Customizable Spare Parts Long-term Supply, Sufficient
Warranty 1 Year Keywords Impact Stone Crusher Machine
Input Size <100mm, <500mm Founction Primary Crushing Or Secondary Crushing
Application Crushing Stones Material Limestone, Granite, Basalt, River Stone, Etc.
Usage Mining And Building Motor Type AC Motor
Weight 8-50t Power Source Electric
Condition New
Highlight

Granite impact stone crusher

,

Electric impact stone crusher
Leave a Message
Product Description

impact crusher for granite rock construction waste crushing

Impact Crusher can crush the large, medium and small size materials (granite, limestone, concrete ,etc.)With max feed size less than 500mm and compression strength less than 350Mpa.It is widely used in metallurgy, mine, cement, chemical engineering, fire resistant materials, ceramics and other industrial sectors, as well as in the expressway construction, water conservancy project, building crushed stone, and machine-made sand process fields, etc.Presently, by practices, its comprehensive function is superior to the cone crusher and the hammer crusher.



Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour 0



Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour 1

Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour 2



Working principle

Impact crusher has two series: two-cavity and three-cavity impact crusher. It is a kind of crushing equipment using impact energy to crush material driven by motor. When the materials get into the area where the plate hammer effects, by whose high speed impact function, the crushed materials are thrown to the impact device above the rotor continuously, and then they are rebounded from the impact liner to the effect area of the blow bar to be crushed again. The materials are crushed from big-size to small-size in the impact cavity repeatedly. The process goes on until the materials are crushed to the required size and then discharged from the down part of the machine.

Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour 3

spare parts

Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour 4

Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour 5



Specifications

Model Size of rotor (mm) Feed opening
(mm)		 Max. feed
size (mm)		 Capacity (t/h) Power of
Motor (kW)		 Weight (t)
PF1010 Φ1000×1050 400×1080 350 50-80 75 12.5
PF1210 Φ1250×1050 400×1080 350 70-130 110 16.5
PF1214 Φ1250×1400 400×1430 350 90-180 132 19
PF1315 Φ1320×1500 860×1520 500 120-250 200 24
PF1320 Φ1320×2000 860×2030 500 160-350 260 27



Application

PF impact crusher is usually used as secondary or tertiary crusher to crusher the not less harder materials with Mosh hardness less than 5.5, the following materials is the favourite of impact crusher.

  • Limestone
  • Gravel
  • Clay & Shale
  • Frac Sand
  • Coal
  • Slag (Aluminum Dross, Copper, Steel, etc…)
  • Fired Clays
  • RAP – Asphalt recycling
  • Concrete without Rebar
  • Floor Tile
  • Glass
  • Concrete Block
  • Stone Crusher
  • Residential, Commercial & Paving Bricks
  • Granite

   Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour 6

packaging & shipping



Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour 7


Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour 8


Factory Outlet PF-1008 PF-1010 Impact Stone Crusher For Granite Quarts Rock Crushing Capacity 40-80 Tons Per Hour 9
